Product Features & Specifications

Visually inspect your firearm's receiver for burrs around the screw holes and remove if necessary. Remove all oil and grease from the holes in the receiver, the base screws and contact surfaces. Place the scope mount base(s) on the receiver. Check for proper fit and alignment. Using a T-15 wrench (supplied with WARNE rings) loosely install the supplied Torx 15 screws. If base(s) fit properly, firmly tighten screws.* WARNE recommends 25 in/lb torque.

*WARNE recommends the use of a REMOVABLE thread locking compound for best results.*

Low profile design allows the use of iron sights when optics are removed.

Full width and depth recoil slots provide a maximum bearing surface for recoil key engagement.

Bases securely mount to your firearm with Torx-style T-15 socket cap screws, 25 in/lb. of torque is recommended.



SKU M902876M

UPC 656813000128
